When you need a smart, dependable contractor or plumber, count on our team of independent professionals for your heating, cooling and water heating needs.
Water Booster Innovations Water Booster Innovations
Water Booster Innovations Water Booster Innovations

DELIVERS UP TO 45% MORE HOT WATER

The new Rheem® Water Heater Booster helps amp up the performance of traditional gas or electric tank water heaters by up to 45%. Need to squeeze in another shower in the morning? Or give your tank water heater more horsepower for holiday guests? Give your current water heater a boost with our new Booster.

More Hot Water

Adds up to 45% capacity1 to water heater tanks, increasing the amount of available hot water and allowing longer hot showers

Saves Energy

Vacation Mode and Eco Mode features allow switching off power to the tank when it isn’t needed, saving energy on water heating

Saves Money

Requires only a one-pro install, takes as little as 45 minutes, and Vacation Mode helps save money on energy bills

Saves Space

Installed on an existing tank or mounted nearby on the wall, it gives a 50-gal. tank the capacity of an 80-gal. tank, without taking up more space

Product Overview

Compatible with both electric and gas tanks, the Rheem Water Heater Booster installs directly to the tank’s hot water outlet or mounts on a nearby wall. It significantly improves the performance of tank-type water heaters by increasing the gallons of hot water delivered and energy efficiency. In fact, it only activates when it senses the water has dropped below the activation temperature.

waterbooster-overview-cover

Quick Installation Makes it Easy to Deliver More Hot Water

  • Easy Installation

    Easy installation on new or existing electric and gas tanks

  • No Additional Electrical

    Uses existing electrical circuit, so there’s no need for additional electrical infrastructure

  • Single Pro Install

    Installation requires only a single pro and takes as little as 45 minutes, as opposed to new, larger tank installations

tank1
tank2
waterbooster-howtoinstall-cover

Technical Features

  • Vacation Mode

    Lowers the set temperature to conserve water and energy while you’re away on vacation

  • Eco Mode

    Conserves energy and saves money by setting a schedule to heat water during the peak times only when needed

  • Max Temperature

    Presets to maximum water temperature preference

  • Activation Temperature

    Ensures unit automatically activates at a set temperature when hot water is needed

  • Freeze Protect

    Works with gas or electric tanks to power on automatically if the internal sensor detects a drop in the water temperature below 60°F

  • ETL Listed

    to UL 499/CSA

  • Low-lead Certified

    to ANSI/NSF 372 by WQA

Product Details

Activation Flow Rate 0.3 GPM
Power 7.2 kW
Voltage 240
Max. Amperage 30 Amps
Dimensions 8 H" x 11½" W x 3¾" D
Phase Single
Required Breaker 1 x 30 Amp Double Pole
Water Connections Intel: ¾ FNPT

Give Your Water Heater a Boost

Ready to get nearly double the hot water out of your current water heater?
